Oszilloskop Leinwanddruck

Oszilloskop - An oszilloscope, previously called an oszillograph , and informally known as a scope, CRO (for kathode-ray oszilloscope), oder DSO (for the more modern digital storage oszilloscope), is a type of electronic test instrument that allows observation of constantly varying signal voltages, usually as a two-dimensional graph of one or electrical difference using the vertikale or y-axis, plotted as a function of time (horizontal or x-axis). Many Signale, for example sound, can be converted to voltages and displayed this way. Signale are operiodic and repeat constantly, so that multiple samples of a signals which is actually varying with time displayed as a steady picture. Many oszilloscopes (Storage oszilloscopes) can also fang non-repeating waveforms for a specified time, and show a steady display of the fänge.
